Thiết bị chuyển mạch Switch công nghiệp 8-port 10/100/1000Base-T(X), DIN Rail, DC18~75V mã YT-RS208-8GT
8 electrical ports full Gigabit unmanaged rail type industrial Ethernet switch
YT-RS208-8GT Gigabit series is a guide rail industrial Ethernet switch developed by Yuantuo Optoelectronics for the needs of wind power, distribution network, transportation, petroleum and petrochemical industries. Including RS208-8GT: Provides 8 Gigabit electrical ports and an aluminum housing with IP40 protection. High-speed packet forwarding capability and abundant backplane bandwidth ensure clear and smooth image transmission. The anti-vibration card rail seat, -40℃~+85℃ extreme environmental temperature adaptability and good EMC performance, make this series of products have the ability to work stably and reliably in harsh industrial environments.
- Features
- main ports: providesGigabit electrical ports, electrical ports 10/100 / 1000 Mbps adaptive;
- Power features:DC9-60V AC110-240V supports dual power source input, anti- reverse protection;
- Transmission distance:electrical port 0-1 0 0 meters ; optical port 20km
- Compliant with standards:IEEE802.3 , IEEE802.3u , IEEE802.3 z standards;
- Security and anti-interference: excellent lightning protection, anti-static and anti-electromagnetic interference capabilities, support 1 relay alarm output ;
- appearance of the structure:IP40 protection level, high-strength aluminum shell , to DIN rail mounting, no fan, low-power design ;
- Ordering information
order information | |
RS208-8GT | 8 gigabit electrical ports, power supply characteristics: DC9-60V , AC110-240V |
packing list:
- Industrial Ethernet Switch
- Installation accessories
- Instruction manual
- Warranty card
- Certificate
- Technical parameters
project description model RS208 Gigabit Series Power section Power supply Support dual power input Adapt to voltage range DC9-60V , AC110-240V Power consumption <5 W Network port parameters network port Electrical port: 10/100 /1000 Mbps Transmission distance Electrical port: 0-100m Network switching specifications Network standard Support IEEE 802.3 , IEEE802.3u, IEEE802.3z Packet buffer 512K bit MAC address capacity 1 K Status indication Power light PWR SPD light Lights up to indicate 10 0 0M , lights off to indicate 10 /100 M L/A electrical port indicator . 1 th (green) light lamp indication Link , blinking indication Act Certification standard
Electromagnetic interference (EMI) FCC Part 15/CISPR22 ( EN55022 ): Class A IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-3 (RS): 10V/m (80~1000MHz) Certification standards Electromagnetic susceptibility (EMS) IEC61000-4-4 (EFT): power line: ±4kV; data line: ±2kV IEC61000-4-5 (Surge): power line: CM±4kV; data line: ± 2 kV IEC61000-6-2 (General Industrial Standard) Anti-vibration IEC 60068-2-6 Impact resistance IEC 60068-2-27 Free fall IEC 60068-2-32 Operating environment Operating temperature – . 4 0 deg.] C ~ 85 deg.] C storage temperature -40 ℃~85 ℃ Humidity (no condensation) 5 -95% Body attributes Dimensions ( L×W×H ) including interface 135 mm* 130 mm* 5 5mm material Aluminum shell colour black weight 850 g reliability Mean Time Between Failure (MTBF) ≥ 5 00 000h Warranty 3- year warranty For more information, please view the data sheet in “Related Downloads”
