Switch managed YT-CM6016-16T , YT-CM6016-8F8T
16 port 100M network managed two-layer rack industrial switch
CM6016-16T is a network-managed industrial-grade Ethernet switch that provides 16 100M electrical ports, adopts a fanless, low power consumption, industrial 4-level design, and has an IP40 protection level. It has a working temperature of -40 ~ 85°C, has a strong sturdiness, is specially designed for network communication in a harsh application environment, and has high EMI/EMS protection capabilities. Supports advanced management and security features, such as IGMP snooping, IEEE 802.1Q VLAN, QoS, port mirroring, SNMP, RMON, etc., and Link Aggregation, WT-Ring and RSTP/STP for redundant backup increase the network Reliability and availability.
- Features
- Provide16 100M electrical ports
- Fanless design,IP40 protection level, impact resistant aluminum shell
- Supportdual power supply redundant backup input, applicable voltage range AC/DC85 ~ 265V
- EMCindustry level 4 electromagnetic compatibility standard
- Command line (CLI ) +WEB interface, can quickly configure network functions
- supporting configurationthe WT-Ring (switching time < 2 0ms ) and STP / RSTP ring network
- SNMP V1/V2c/V3, support WTNMS integrated network management
- Ordering information
order information | |
CM6016-16T | 16 100M electrical ports, power supply characteristics: AC/DC85~265V |
CM6016-8F8T | 8 100M optical ports + 8 100M electrical ports, power supply characteristics: AC/DC85~265V |
packing list:
- Industrial Ethernet Switch
- Installation accessories
- One U disk, including user manual
- Warranty card
- Certificate
- Technical parameters
interface Serial port: RS-232 (interface type: RJ45 slot) 100M electrical port: 10/100Mbps adaptive, Full/Half duplex mode, support MDI/MDI-X.
LED indicator: PWR1, PWR2, ALM, Link/ACT, SPD, SYS
Relay: 3 channels, power 1 channel, power source 2 channel, power alarm channel.
Support standard IEEE 802.3 10BaseT IEEE 802.3u 100BaseT and 100BaseFX
IEEE 802.3z 1000BaseFX
IEEE 802.3x flow control
IEEE 802.1D STP
IEEE 802.1w RSTP
IEEE 802.1Q VLAN
protocol IGMP Snooping, GMRP, GVRP, SNMPv1/v2c/v3, TFTP, SNTP, RMON, HTTP, SSH, Telnet, Syslog, LLDP, EtherNet/IP, Modbus/TCP MIB: MIB-II, BRIDGE MIB, Ethernet MIB, IF MIB, RMON MIB Group 1, 2, 3, 9
Switch properties Qos queue: 4 VLAN-ID: 1-4094 Backplane bandwidth: 3.2Gbps MAC address table: 8K
Message buffer size: 3Mb
Power requirement Input voltage: support two redundant backup, AC/DC85~265V Input current: Max 0.2A
Physical properties Shell: Aluminum shell, IP40 protection Size: 440mm*320mm*44mm
Weight: 3100g
Installation method: rack
working environment Working temperature: -40 ~ 85°C (-40~ 185°F) Storage temperature: -40 ~ 85°C (-40 ~ 185°F)
Environmental relative humidity: 5 ~ 95% (non-condensing)
Industry standards and Certification
Electromagnetic Interference (EMI): FCC Part 15/CISPR22 (EN55022): Class A Electromagnetic susceptibility (EMS):
IEC61000-4-2 (ESD) Level 4, IEC 61000-4-3 (RS) Level 3, IEC 61000-4-4 (EFT) Level 4, IEC 61000-4-5 (Surge) Level 4, IEC 61000- 4-6(CS) Level 3
Vibration resistance: IEC 60068-2-6
Shock resistance: IEC 60068-2-27
Free fall: IEC 60068-2-32
Note: Please check the latest certification status on the official website of Yuantuo.
MTBF (Mean Time Between Failure)
Time: 500000h
Quality Assurance 3 years For more information, please view the data sheet in “Related Downloads”
