Bộ chuyển đổi công nghiệp WINTOP YT-RS203-1GF2GT | Bộ chuyển đổi quang điện 2 cổng 10/100/1000Base-T(X) + 1 cổng quang 1000Base-X(SFP), gắn DIN, nguồn DC18~75V

RS203 Gigabit series is a guide rail type industrial-grade transceiver developed by Yuantuo Optoelectronics for the needs of wind power, distribution network, transportation, petroleum and petrochemical industries. Including RS203-1GF2GT: Provides 1 Gigabit optical port and 2 Gigabit electrical ports, with an aluminum housing with IP40 protection. High-speed packet forwarding capability and abundant backplane bandwidth ensure clear and smooth image transmission. The anti-vibration card rail seat, -40℃~+85℃ extreme environmental temperature adaptability and good EMC performance, make this series of products have the ability to work stably and reliably in harsh industrial environments.

• Features
• main ports: providesGigabit optical ports and Gigabit electrical ports, electrical ports 10/100 / 1000 Mbps adaptive;
• Power features:DC9-60V AC110-240V supports dual power source input, anti- reverse protection;
• Transmission distance:electrical port 0-1 0 0 meters ; optical port 20km
• Compliant with standards:IEEE802.3 , IEEE802.3u , IEEE802.3 z standards;
• Security and anti-interference: excellent lightning protection, anti-static and anti-electromagnetic interference capabilities, support 1 relay alarm output ;
• appearance of the structure:IP40 protection level, high-strength aluminum shell , to DIN rail mounting, no fan, low-power design
• Ordering information

packing list:

• Fiber optic transceiver
• Installation accessories
• Instruction manual
• Warranty card
• Certificate
• • Technical parameters

  project			description
  model			RS203 Gigabit Series
  Power section		Power supply	Support dual power input
  		Adapt to voltage range	DC9-60V , AC110-240V
  		Power consumption	＜5 W
  Network port parameters		network port	Electrical port: 10/100 /1000 Mbps Optical port: 1000Mbps
  		Transmission distance	Electrical port: 0-100m Optical port: 20km
  Network switching specifications		Network standard	Support IEEE 802.3 IEEE802.3u.IEEE802.3z
  		Packet buffer	512K bit
  		MAC address capacity	1 K
  Status indication		Power light	PWR
  		SPD light	Lights up to indicate 10 0 0M , lights off to indicate 10 /100 M
  		L/A electrical port indicator	. 1 th (green) light lamp indication Link , blinking indication Act
  Certification standard		Electromagnetic interference (EMI)	FCC Part 15/CISPR22 ( EN55022 ): Class A
  			IEC61000-4-2 (ESD): ±8kV contact discharge, ±15kV air discharge
  			IEC61000-4-3 (RS): 10V/m (80～1000MHz)
  Certification standards		Electromagnetic susceptibility (EMS)	IEC61000-4-4 (EFT): power line: ±4kV; data line: ±2kV
  			IEC61000-4-5 (Surge): power line: CM±4kV; data line: ± 2 kV
  			IEC61000-6-2 (General Industrial Standard)
  	Anti-vibration		IEC 60068-2-6
  	Impact resistance		IEC 60068-2-27
  	Free fall		IEC 60068-2-32
  Operating environment	Operating temperature		– . 4 0 deg.] C ~ 85 deg.] C
  	storage temperature		-40 ℃～85 ℃
  	Humidity (no condensation)		5 -95%
  Body attributes	Dimensions ( L×W×H ) including interface		110 mm * 95 mm * 30 mm
  	material		Aluminum shell
  	colour		black
  	weight		350 g
  reliability	Mean Time Between Failure (MTBF)		≥ 5 00 000h
  	Warranty		3- year warranty

  For more information, please view the data sheet in “Related Downloads”

•
